Purpose-built front and rear carbon fiber rims with incredible impact resistance and outstanding trail damping properties.
27.5" | 30 Wide Int | 1837g
The Purpose
Tailored to maximise traction and accuracy on the unrelenting stages of the Enduro World Series. Tuned for front wheel comfort and precision and rear wheel strength and durability. Developed in the UK and Proven around the globe during the 2022 EWS season under Fergus Ryan.
Proprietary front and rear carbon layup and weave, with specific front and rear spoke gauges for a fully tuned carbon wheel system. What sets Race Enduro apart is the tailored front and rear rim carbon layups, each aimed to offer specific ride properties. The front is tuned for comfort, while the rear can withstand impacts and compressions. All this while providing precise control and reducing fatigue during those long EWS stages.
Proven Carbon Race Enduro Competitor Impact Testing
The HUNT Engineering team uses our custom impact rig to test Proven Race Enduro alongside leading competitors and our own wheelsets. The graph below shows the impact energy (J) recorded at the first sign of failure. Our new Proven Race Enduro exhibits an impact strength 12J greater than that of the HUNT All-Mountain Carbon H_Impact wheelset.
The Purpose
Tailored to maximise traction and accuracy on the unrelenting stages of the Enduro World Series. Tuned for front wheel comfort and precision and rear wheel strength and durability. Developed in the UK and Proven around the globe during the 2022 EWS season under Chloe Taylor and Fergus Ryan.
Proprietary front and rear carbon layup and weave, with specific front and rear spoke gauges for a fully tuned carbon wheel system. What sets Race Enduro apart is the tailored front and rear rim carbon layups, each aimed to offer specific ride properties. The front is tuned for comfort, while the rear can withstand impacts and compressions. All this while providing precise control and reducing fatigue during those long EWS stages.
Proven Carbon Race Enduro Competitor Impact Testing
The HUNT Engineering team uses our custom impact rig to test Proven Race Enduro alongside leading competitors and our own wheelsets. The graph below shows the impact energy (J) recorded at the first sign of failure. Our new Proven Race Enduro exhibits an impact strength 12J greater than that of the HUNT All-Mountain Carbon H_Impact wheelset.
Key Features
Our no compromise enduro wheel system.
- Rims | Hookless Built to offer the same levels of impact resistance as our legendary All Mountain Carbon H_IMPACT wheelset but with the benefits of added traction and compliance. Updated 30mm internal rim profiles make the most of modern Enduro tires, while a 23mm deep design increases strength.
- Hubs | Large body Hunt Enduro front hub and 5 degree RapidEngage rear hub, boost (110/148) spacing. Large double sealed cartridge bearings. Rock Shox Torque Caps for Boost hubs are available.
- Axles | Extra thick 17mm 7075-T6 axles for increased strength and stiffness. Reducing flex in the hub also helps to increase bearing life.
- Tires | Optimized for 2.35"-2.6" tire widths, but also work very well with 2.25"-2.8".
- Bearings | Super smooth, replaceable, Revo bearings offer fast rolling performance. Dual full-contact seals and long-lasting, heat-resistant grease protect against water ingress for longer service intervals.
- Hand-built | All of our wheels are built and finished by hand, inclusive of a full quality control inspection.
- Included | Tubeless tape, valve & spokes.
- Weight | 1837g
- Also available in and
The Experts' View
Full Specs
Rims
- 30mm internal rim width, 37.2mm external and 23mm depth
- Front and rear-specific carbon construction, built for front-wheel compliance and rear-wheel strength.
- Tubeless-ready – designed to work excellently with tubeless tires. Tubeless-rim tape and valves included.
- H-lock bead-seat up-kicks for easy and secure tubeless installation.
- Available in 29in, 27.5in and Mullet configurations.
Spokes
- J-bend cold drawn.
- 28F/28R spoke count.
- Front Spokes are Pillar PSR TB2016, with a narrower 1.6mm central butted diameter.
- Rear Spokes are Pillar PSR 2018 with a larger 1.8mm central diameter.
- Black stainless treatment.
Nipples
- Hard-anodized alloy strength.
- Lightweight DNS (double square nipple) body for external adjustment and hex head for easy internal adjustment/tensioning.
- Long 16mm thread for durability.
- 14 gauge.
- Black finish
Tires Info
- Maximum tire pressure for this rim: up to 2.5" do not exceed 40psi. 2.6 - 3.0" - do not exceed 30psi. Please do not exceed the maximum pressure stated on your tire.
- Optimised for 2.35"-2.6" tire widths, but also work very well with 2.25"-2.8".
- Designed to work perfectly with tubeless tires.
- Suitable tubeless are available to be fitted to your Hunt Proven Carbon Race Enduro Wheels.
Axle/Hub Size
- Boost - 148x12mm (Rear) with 110x15mm (Front). Rock Shox Torque Caps available - request in notes at checkout.
- SRAM/Shimano 8/9/10/11 speed, Shimano Microspline and SRAM XD compatible.
Front Hub
- Forged and CNC’d 6061-T6 heat treated aluminium alloy body.
- 110x15mm spacing. Rock Shox Torque Caps for Boost option available - just add a comment in the notes section on the cart page.
- 7075-T6 aluminium alloy axles.
- 6 bolt disc mount.
- Polished anodized black finish with laser graphics.
Rear Hub
- Forged and CNC’d 7075-T6 heat treated aluminium alloy Hub body.
- RapidEngage 5 degree, 3x2 freehub for increased resistance to the extra torque generated.
- H_CERAMIK freehub body reinforcement coating (Shimano/Sram HG body) provides excellent durability and protects against cassette sprocket damage to the freehub often seen on standard alloy freehub bodies.
- 148x12mm spacing (boost)
- 6 bolt disc mount
- 9/10/11 speed Shimano/SRAM compatible freehub, Shimano Microspline and SRAM XD Driver version available.
- Polished anodized black finish with laser graphics.
Bearings
- Super smooth precision REVO bearings.
- Dual full-contact seals.
- Cartridge design for convenient servicing.
Warranty, Support and Weight Limits
These wheels come with H_CARE (Free Lifetime Crash Replacement) for the first owners when used with single crown forks. Read all about it .
All HUNT wheels models have to pass our harsh rolling-drum fatigue tests for rider weight limits, please see here for more details. Max system weight 297lbs (system weight – total weight of fully kitted up rider, bike and luggage). If a rider is over 273lbs then an experienced bike mechanic should check the wheel regularly and it is advisable to use tires at max 40psi as this will reduce the fatigue on the wheelset.
We are cyclists ourselves and do of course go above and beyond to offer excellent service if you ever do experience any issues. We carry full spares at very reasonable prices and offer complete support.
60 Day Ride & Return Period. We are certain you'll be impressed by the acceleration, low-weight, speed and durability of our wheels. We are cyclists and as such strive to offer class leading service and support. Buy with confidence, if for any reason you wish to return the wheels for a full refund of your order you can do so up to a full 60 days after you receive them whether they have been ridden or not.
