All-MTN Carbon: Proven in the Enduro World Series, the All-Mountain Carbon’s front and rear specific wheels are optimised for traction up front and high impact strength out back.
Responsive, compliant and incredibly strong.
29" | 28mm Wide Int. | 1876g
The Purpose
Tested on the world stage under Chloe Taylor in their Enduro World Series campaigns, the All-Mountain Carbons are built to handle anything you can throw at them; be it the infamous rocks of Finale, big days on the Front Range or even the local push up DH run.
The All-Mountain Carbon combines our 5° RapidEngage hubs and triple butted Pillar PSR spokes with front/rear optimised rims, to build an incredibly strong yet compliant wheelset.
The Purpose
Tested on the world stage under Chloe Taylor in their Enduro World Series campaigns, the All-Mountain Carbons are built to handle anything you can throw at them; be it the infamous rocks of Finale, big days on the Front Range or even the local push up DH run.
The All-Mountain Carbon combines our 5° RapidEngage hubs and triple butted Pillar PSR spokes with front/rear optimised rims, to build an incredibly strong yet compliant wheelset.
Key Features
We see wheels as a system, not an single component
- Rims | H_IMPACT Unidirectional T24/30 with 3K weave reinforced spoke holes, 28mm wide (internal), Extra thick sidewalls for impact protection and V:Asborb resin to reduce vibration.
- Hubs | Large body NDRO front hub and 5 degree RapidEngage rear hub, boost (110/148 ) spacing. Large double sealed cartridge bearings. Rock Shox Torque Caps for Boost hubs are available.
- Spokes | 28F/32R Spoke Count, Triple Butted (2.2-1.6-2.0) PSR reinforced Pillar Spokes
- Tires | Optimised for 2.3"-2.5" tires set up Tubeless, but also work very well with 2.25"-2.6". Also great with standard tires and tubes.
- Axles | Extra thick 17mm 7075-T6 axles for increased strength and stiffness. Reducing flex in the hub also helps to increase bearing life.
- Weight | 1876 G 29"
The Experts' View
Full Specs
Rims
- 28mm internal width ideal for 2.3"-2.5" tire widths, but also work very well with 2.25"-2.6".
- H_IMPACT Unidirectional T24/30 with 3K weave reinforced spoke holes.
- Extra thick sidewalls for impact protection and V:Asborb resin to reduce vibration.
- Tubeless-ready – designed to work best with tubeless tires. Tubeless-rim tape and valves included.
- Hookless H-lock bead-seat up-kicks for easy and secure tubeless installation.
Spokes
- J-bend cold drawn.
- 28F/32R spoke count.
- Made from high grade T302 (18/10) stainless steel wire by Sandvik Sweden.
- Triple butted 2.0-1.6-2.0 (then 2.2 at the head for the patented Pillar Spoke Re-enforcement).
- Black stainless
Nipples
- Hard-anodized alloy for weight reduction and strength.
- Square body for external adjustment and hex head for easy internal adjustment/tensioning.
- Long 14mm thread for durability.
- 14 gauge.
- Black finish
Tires Info
- Maximum tire pressure for this rim: Up to 2.5" do not exceed 40psi. 2.6 - 3.0" - do not exceed 30psi. Please do not exceed the maximum pressure stated on your tire.
- Designed to work perfectly with tubeless and non-tubeless tires.
- Suitable tubeless MTB tire combinations from Schwalbe and Maxxis are available to be fitted to your Hunt TrailWide Wheels.
Axle Size
- 148 (Boost) x 12mm (Rear) and 110x15mm Boost (Front) standard. Rock Shox Torque Caps available - just add a comment in the notes section on the cart page.
- SRAM/Shimano 8/9/10/11 speed, Shimano Microspline and SRAM XD compatible.
Front Hub
- Oversized hub and axles.
- Forged and CNC’d 7075-T6 heat treated aluminium alloy body.
- 110x15mm spacing. Rock Shox Torque Caps for Boost option available - just add a comment in the notes section on the cart page.
- Oversized 17mm 7075-T6 aluminium alloy axles.
- 6 bolt disc mount.
- Polished anodized black finish with laser graphics.
Rear Hub
- Forged and CNC’d 7075-T6 heat treated aluminium alloy Hub body.
- 148 (boost) x 12mm spacing.
- RapidEngage 5 degree, 3x2 freehub for increased resistance to the extra torque generated.
- 9/10/11 speed Shimano/SRAM, Shimano Microspline and Sram XD compatible freehubs available.
- 6 bolt disc mount.
- Polished anodized black finish with laser graphics.
Bearings
- Precision sealed cartridge replaceable units.
- Large diameter ball bearings for extra durability.
- Dual full-contact rubber seals.
Warranty, Support and Weight Limits
All HUNT wheels models have to pass our harsh rolling-drum fatigue tests for rider weight limits, please see here for more details. 264lbs is the upper recommended rider weight limit for these wheels. Please include the weight of any luggage in your total rider weight when choosing the correct wheels. If a rider is over 240lbs then an experienced bike mechanic should check the wheel regularly and it is advisable to use tires at max 40psi as this will reduce the fatigue on the wheelset.
We are cyclists ourselves and do of course go above and beyond to offer excellent service if you ever do experience any issues. We carry full spares at very reasonable prices and offer complete support.
60 Day Ride & Return Period. We are certain you'll be impressed by the acceleration, low-weight, speed and durability of our wheels. We are cyclists and as such strive to offer class leading service and support. Buy with confidence, if for any reason you wish to return the wheels for a full refund of your order you can do so up to a full 60 days after you receive them whether they have been ridden or not.
Reviews
Bike Magazine and Website Experts' Views
 | Singletracks Review"For riders upgrading with a budget in mind, the Hunt All-Mountain H_Impact carbon wheels are hard to beat, if not impossible" |
 | 4.5/5 BikePerfect Review"Hunt’s state of the art carbon trail/enduro wheels re-write the performance-to-price benchmark. Instant pedal connection and steering responsiveness underlined with a warmly dynamic high traction feel." |
 | 4/5 Mountain Bike Action Review"Hunt delivers an impressive package with the H_Impact Carbon wheels, one that’s nearly half the price we’d expect from looking at the spec sheet. They are lightweight and buttery smooth. While there are lighter, stiffer and more race-ready options out there, you’d be hard-pressed to find another option that can hang with Hunt when it comes to value." |
 | TGR Tested : The Best Carbon MTB wheels of 2019"Hunt's All Mountain carbon wheels have shockingly good performance, given the fact they are half the price of the competition." |
 | IMB Review"A truly great set of carbon wheels at a ridiculously good price. Hunt has nailed it with these hoops, and the crash replacement policy is the icing on the cake." |
